The bottom panels

← back to the README

The panel under the table describes whichever session the cursor is on. ← and → move between panels, 1–9 jump to one, Tab cycles through them, and Shift+↑/↓ scrolls inside the active one.

Three of them repay a closer look, and so does the conversation view i opens.

Tool Activity

Each invocation shows the time, its arguments, and — where the transcript supports it — what it did:

19:16 main    ~/cctop/src/ui/render.rs     +43 -24   122ms ↓498.5K ↑ 1.2K
19:34 ↳aa1b82 ~/cctop/src/quota.rs          +2 -0    88ms ↓ 41.2K ↑  310
19:41✗main    cargo test --all-targets               1.4s  ↓ 12.0K ↑  180

• origin — main for the session itself, or ↳<agent-id> for a subagent. Subagent activity is interleaved into the same log, so without this there’s no way to tell an agent’s edits from the parent’s.
• ✗ and a red row — the call reported an error. Claude records this per call, OpenCode and Gemini record a tool status, Devin’s comes from its database rather than its transcript, and Codex is read from the sandbox’s own result line and exit code. Cursor, Pi and Windsurf record no tool outcome at all, so their calls are never marked.
• +N -M — lines added and removed, from the edit result’s patch. Press v to expand the diff inline beneath the row.
• duration — wall time from the call being issued to its result arriving.
• ↓ / ↑ — tokens in and out for the assistant turn that issued the call. Claude only; Codex transcripts don’t tie token counts to individual calls.

That last one deserves a caveat: billing is per API request, not per tool call. When one turn issues several calls they all show that turn’s figures, marked with a leading *. Dividing the total between them would invent precision the transcript doesn’t contain. ↓ includes cache reads, which is why it tracks total context size rather than the size of any one call.

Codex tools are decoded too: apply_patch shows the files it touched and its line counts, update_plan shows progress and the step in flight, and write_stdin distinguishes a real write from a poll for more output.

Reading the conversation

The panels summarise what a session did; i shows what it said — or Enter and Read the conversation. It opens the selected row’s transcript full-screen, a remote row’s too (read over the same ssh link), at the end, so the agent’s last reply is the first thing on screen. It reads what cctop serve’s conversation page reads, so every harness that page shows is here, for the times you are on ssh with no browser to open.

• Each turn is headed by who spoke and when: you in the accent colour, the agent in its harness’s, with the local time (and the date, for an older turn) and how long ago. What you typed sits behind a bar in that same colour, so a prompt is easy to find in a page of replies. Thinking is dim and italic; a compaction is a rule across the page.
• Replies are rendered as markdown: headings, bold and italic, inline code, fenced blocks on a shaded ground with their language named, lists, quotes, tables and rules. Links are OSC 8 hyperlinks, so a click opens them even when they wrap; on a terminal that cannot do that (TERM=dumb or linux) the URL is printed after its label. What you typed is shown as you typed it. Code is not syntax-highlighted.
• A subagent’s call is one line too, naming the agent and how much it did (3 turns · 12 tools · 2m10s); opened, it shows the agent’s report. A background agent that never handed back shows its last message instead, labelled as that. a opens the agent’s own turns, and Esc comes back to the same place; opening the reader on a subagent’s row in the table goes straight to its turns.
• Tool calls are one line each until you open them: the tool, its argument, and how many lines opening it would add. Enter opens the calls of the turn you are reading; t opens every one.
• Tool output keeps its colours. cargo’s green, pytest’s red and git’s diff colours come through, folded to sixteen colours on a terminal that has only those and dropped under NO_COLOR. Anything else a program wrote — cursor moves, line erases, window titles — is removed, so it cannot scribble over the view. Expanded Tool Activity rows get the same treatment.

A session paged back far with u can run to thousands of turns. It is laid out once for the terminal’s width, and scrolling it lays nothing out again.

Context breakdown

CTX% says the window is 68% full. The Context panel says what is in it — Claude sessions only, since no other provider’s transcript reports per-request usage.

Window   181.4K of 200K

Unaccounted    ━━━━━━━━━━━━━━━━────────────────────────   62.1K  34%
Tool output    ━━━━━━━━━━━━────────────────────────────   43.5K  24%
Startup        ━━━━━━━━━───────────────────────────────   34.5K  19%
Tool input     ━━━━━━━━────────────────────────────────   29.0K  16%
Attachments    ━━━━────────────────────────────────────    9.1K   5%
Assistant text ━━──────────────────────────────────────    3.6K   2%

Two of those numbers are measured and the rest are estimated, and the panel never blurs the line:

• Window and Startup come from the usage figures the API itself reported. Startup is the first request of the live segment — everything the harness sends before the conversation begins: the system prompt, the tool schemas, CLAUDE.md, the skills index, and, after a compaction, the summary. It cannot be split further, because the transcript never records what was sent, only that it was.
• Tool output, Tool input, Attachments, Your messages and Assistant text are estimated from how many characters the transcript holds, at 2.75 characters per token. That constant is fitted rather than assumed: across 167 local sessions, the characters a transcript accumulates divided by the context growth the API reports over the same span lands there, well under the usual prose rule of thumb because this content is mostly code, JSON and file paths.
• Unaccounted is the remainder, and it is deliberately a bar of its own rather than being spread across the categories that happen to be measurable. It runs around a third of the window. Most of it is thinking — Claude Code writes those blocks with the text stripped and only the signature left, so there is nothing to measure — plus the <system-reminder> text the harness splices into each turn without recording it, plus estimation error.

A compaction resets the whole thing: everything before the summary has left the window, so counting across one would describe a context that no longer exists. Subagent turns are excluded too — they run against their own windows, and only the report a subagent hands back is in the parent’s, where it lands in Tool output like any other result.

When the estimate overshoots the window there is no gap to draw, and the panel says so instead of clamping: it means the harness has dropped context that the transcript still holds.

Given the height, the bar folds into a block map, like a memory map of the window: the same cells in the same order, filling rows left to right and top to bottom, a quarter of the panel’s rows and up to six. One row of eighty cells spends 2.5K of a 200K window per cell; four rows spend 625 tokens, which is the difference between a small category showing and vanishing. The footnote says what a cell is worth. Every category in the window gets at least one cell however small its share, so nothing in the legend is missing from the map. On the map, the free space past the auto-compaction threshold is drawn as · rather than a lone ┊, because that is a region — room the harness reclaims before it is ever reached — and one marker cell is lost in a grid. A panel too short to spare the rows keeps the one-row bar.

Under the bar, How it filled charts the window across every request the session made. The bar answers “what is in there”; the chart answers “how did it get that full”, which is the part that changes what you do next. A window that climbed evenly is a conversation that grew and will keep growing. One that stepped is a handful of large tool results, and the same call will do it again. A sawtooth is a session living on compactions, paying to rebuild its context over and over. The chart spans the whole session rather than the live segment, because a compaction is the most interesting thing that can happen to a context window and it is the only view that can show one.

Preview

The last panel, 9, is the selected row’s tab, watched from the dashboard: the agent’s screen as it is right now, updating while you look, without leaving the table to see whether it has finished or is asking you something.

It is a window, not a way in. Nothing typed on the dashboard reaches the agent, and the pane is not resized to fit the panel — the agent keeps drawing at the size its tab gave it, and the panel shows as much of that as fits. When the screen is taller than the panel, the bottom of what the agent has drawn is what stays, because that is where its prompt and its questions are. The bottom border names the tab and the key that goes to it, Alt+2 onwards.

A tab you have switched away from gives up its rmux client, so there is no screen of cctop’s own to show. The panel asks rmux for the screen instead, twice a second and only while the panel is on show; that is a read, and rmux resizes nothing for it.

A row with no tab says so in one line: a opens a running session’s terminal in one, R resumes a stopped session in one, and either then shows here live. A row from another machine has no tab here to show.
